Expanded Metal
PSM would appreciate the opportunity to handle any of your expanded metal needs. We offer one of the widest ranges of expanded metal from stock or handle any of your custom fabricated needs. Stocked sizes are typically 48" x 96", non standard sheets sizes are available as well. We stock steel, 304/316 stainless, and aluminum. Please contact our sales staff today to help meet your requirements!
Measuring and Ordering Material
1. Specify opening, gauge of material, pattern,(standard or flattened), and desired alloy.
2. Specify overall dimensions of material, and quantity required.
Flattened expanded metal carbon steel
STYLE | LBS PER 100 SF | STANDARD SHEET SIZE | DESIGN SIZES INCHES | OVERALL THICKNESS | % OPEN AREA | |
|---|---|---|---|---|---|---|
| SWD | LWD | |||||
| 1/4″ X #20 | 83 | 48" X 96" | 0.25 | 1.03 | 0.03 | 47 |
| 1/4" X #18 | 111 | 48" X 96" | 0.25 | 1.03 | 0.04 | 40 |
| 1/2" X #20 | 40 | 48" X 96" | 0.5 | 1.26 | 0.029 | 72 |
| 1/2" X #18 | 66 | 48" X 96" | 0.5 | 1.26 | 0.039 | 69 |
| 1/2" X #16 | 82 | 48" X 96" | 0.5 | 1.26 | 0.05 | 60 |
| 1/2"X #13 | 140 | 48" X 96" | 0.5 | 1.26 | 0.07 | 57 |
| 1/2"X #16 | 51 | 48" X 96" | 0.92 | 2.1 | 0.048 | 75 |
| 3/4" X #13 | 51 | 48" X 96" | 0.92 | 2.1 | 0.048 | 75 |
| 3/4" X #9 | 171 | 48" X 96" | 0.92 | 2.1 | 0.12 | 63 |
| 1" X #16 | 41 | 48" X 96" | 1.09 | 2.56 | 0.048 | 77 |
| 1-1/2" X #16 | 38 | 48" X 96" | 1.33 | 3.2 | 0.048 | 82 |
| 1-1/2" X #13 | 57 | 48" X 96" | 1.33 | 3.2 | 0.07 | 80 |
| 1-1/2" X #9 | 111 | 48" X 96" | 1.33 | 3.2 | 0.11 | 77 |
| FLATTENED EXPANDED STAINLESS STEEL | ||||||
| 1/2" X #18 | 69 | 48" X 96" | 0.5 | 1.25 | 0.04 | 68 |
| 1/2" X #16 | 86 | 48" X 96" | 0.5 | 1.25 | 0.05 | 60 |
| 1/2" X #13 | 178 | 48" X 96" | 0.5 | 1.25 | 0.08 | 56 |
| 3/4" X #16 | 57 | 48" X 96" | 0.92 | 2.1 | 0.05 | 75 |
| 3/4" X #13 | 87 | 48" X 96" | 0.92 | 2.1 | 0.07 | 74 |
| 3/4" X #9 | 195 | 48" X 96" | 0.92 | 2.1 | 0.119 | 64 |
| 1-1/2" X #16 | 43 | 48" X 96" | 1.33 | 3.2 | 0.05 | 83 |
| 1-1/2" X #13 | 65 | 48" X 96" | 1.33 | 3.2 | 0.079 | 79 |
| 1-1/2" X #9 | 131 | 48" X 96" | 1.33 | 3.2 | 0.119 | 76 |
| FLATTENED EXPANDED ALUMINUM | ||||||
| 1/2" X .050 | 25 | 48" X 96" | 0.5 | 1.27 | 0.04 | 57 |
| 1/2" X .080 | 41 | 48" X 96" | 0.5 | 1.27 | 0.06 | 57 |
| 3/4" X .050 | 16 | 48" X 96" | 0.92 | 2.12 | 0.04 | 73 |
| 3/4" X .080 | 30 | 48" X 96" | 0.92 | 2.12 | 0.07 | 66 |
| 3/4" X .125 | 61 | 48" X 96" | 0.92 | 2.12 | 0.095 | 55 |
| 1-1/2" X .080 | 20 | 48" X 96" | 1.33 | 3.15 | 0.055 | 75 |
| 1-1/2" X .125 | 40 | 48" X 96" | 1.33 | 3.15 | 0.08 | 65 |
| STANDARD (RAISED) EXPANDED CARBON STEEL | ||||||
| 1/4" X #1 | 114 | 48" X 96" | 0.25 | 1 | 0.125 | 43 |
| 1/2" X #18 | 70 | 48" X 96" | 0.5 | 1.2 | 0.155 | 77 |
| 1/2" X #16 | 86 | 48" X 96" | 0.5 | 1.2 | 0.157 | 71 |
| 1/2" X #13 | 147 | 48" X 96" | 0.5 | 1.2 | 0.182 | 58 |
| 3/4" X #13 | 54 | 48" X 96" | 0.92 | 2 | 0.186 | 85 |
| 3/4" X #9 | 80 | 48" X 96" | 0.92 | 2 | 0.195 | 78 |
| 3/4" X #9 | 180 | 48" X 96" | 0.92 | 2 | 0.3 | 66 |
| 1" X #16 | 44 | 48" X 96" | 1.09 | 2.4 | 0.182 | 86 |
| 1-1/2" X #16 | 40 | 48" X 96" | 1.33 | 3 | 0.211 | 89 |
| 1-1/2" X #13 | 60 | 48" X 96" | 1.33 | 3 | 0.215 | 86 |
| 1-1/2" X #9 | 120 | 48" X 96" | 1.33 | 3 | 0.295 | 75 |
| STANDARD (RAISED) EXPANDED STAINLESS STEEL | ||||||
| 1/2" X #18 | 73 | 48" X 96" | 0.5 | 1.2 | 0.164 | 77 |
| 1/2" X #16 | 91 | 48" X 96" | 0.5 | 1.2 | 0.164 | 70 |
| 1/2" X #13 | 187 | 48" X 96" | 0.5 | 1.2 | 0.225 | 58 |
| 3/4" X #16 | 60 | 48" X 96" | 0.92 | 2 | 0.2 | 85 |
| 3/4" X #13 | 91 | 48" X 96" | 0.92 | 2 | 0.2 | 78 |
| 3/4" X #9 | 205 | 48" X 96" | 0.92 | 2 | 0.3 | 67 |
| 1-1/2" X #16 | 45 | 48" X 96" | 1.33 | 3 | 0.22 | 89 |
| 1-1/2" X #13 | 68 | 48" X 96" | 1.33 | 3 | 0.22 | 86 |
| 1-1/2" X #9 | 137 | 48" X 96" | 1.33 | 3 | 0.28 | 75 |
| STANDARD (RAISED) EXPANDED ALUMINUM | ||||||
| 1/2" X .050 | 27 | 48" X 96" | 0.5 | 1.2 | 0.158 | 70 |
| 1/2" X .080 | 44 | 48" X 96" | 0.5 | 1.2 | 0.186 | 60 |
| 3/4" X .050 | 17 | 48" X 96" | 0.92 | 2 | 0.2 | 90 |
| 3/4" X .080 | 41 | 48" X 96" | 0.92 | 2 | 0.2 | 76 |
| 3/4" X .125 | 65 | 48" X 96" | 0.92 | 2 | 0.305 | 66 |
| 1-1/2" X .080 | 22 | 48" X 96" | 1.33 | 3 | 0.24 | 87 |
| 1-1/2" X .125 | 43 | 48" X 96" | 1.33 | 3 | 0.3 | 78 |
